BitFenix Prodigy has been a huge success since it was released in 2012. It has become a popular case for builders, modders, gamers, HTPC users and for those who just wanted to buy anything newly released. With its unique design and reasonable price tag, it is sold like a pancake. For a M-ITX chassis, the BitFenix Prodigy is quite huge and some modders thought of redesigning it so they could fit a micro ATX board in it. BitFenix’s Facebook fanpage has been a busy page that time when fans, including myself, are asking for a spacy Prodigy where we could install a micro-ATX motherboard. For me, as a micro-ATX board user, I couldn’t just switch to a M-ITX board with less features just to have a Prodigy. Additionally, those cute motherboards are quite expensive.

That said, BitFenix was kind enough and responsive to their fans posting a picture of their product team holding a note that if ever, the picture reached at least 2,000 likes, they will think about the requests. Yeah, marketing strategy, and they are quite successful, hence, the birth of BitFenix Prodigy M.

Features and Specifications

Materials Steel, Plastic
Colors (Int/Ext) Black/Black, White/White
Dimensions (WxHxD) 250 x 404 x 359mm
Motherboard Sizes Micro ATX, Mini-ITX
5.25” Drive Bays x 1 (removable)
3.5” Drive Bays x 4 (2 + 2)
2.5” Drive Bays x 5 (3 + 2)
Cooling Top 120mm x 2 (optional)
Cooling Bottom 120mm x 2 (1 included) or 200mm x 1(optional) or 230mm x 1 (optional)
Cooling Rear 120mm x 1 (included) or 140mm x 1 (optional)
PCI Slots x 5
I/O USB 3.0 x 2, HD Audio
Power Supply PS2 ATX (bottom, multi direction)
Extras FyberFlex™ Composite handles, SofTouch™ surface treatment, heat shield

Unboxing and Bundled Accessories

The box of the Prodigy M is pretty standard with a large logo at the front, product name on both sides and some of its features at the back.

OLYMPUS DIGITAL CAMERA

OLYMPUS DIGITAL CAMERA

Inside the box you’ll find a simple, easy to read installation manual, a box containing cable ties, bunch of black screws and washers and a USB 3.0 to 2.0 converter which is very useful for those who doesn’t have a USB 3.0 capable motherboard. You will not have a dead front USB port with this.

OLYMPUS DIGITAL CAMERA

BitFenix Prodigy M Exterior

The BitFenix Prodigy M is very identical to its M-ITX brother, the Prodigy. It sports an unfiltered mesh panel on the front with a shiny BitFenix logo at the bottom and a blank 5.25 bay at the top where you could install an ODD or a fan controller.

OLYMPUS DIGITAL CAMERA

From this angle you will see that your motherboard will be installed in an inverse mounted position.  The five mesh-covered PCI slots features a tool-less mechanism so you could install you video card, sound card etc. without screws. There’s a 120mm/140mm fan mount with a pre-installed 120mm fan I must add, and since the PSU is front mounted, the power socket is located at the bottom of the I/O panel.

OLYMPUS DIGITAL CAMERA

Here you can see the Fiberflex handle/feet extensions that you might think weak because it is made of plastic. It actually can carry the weight of your PC with all parts installed.

OLYMPUS DIGITAL CAMERA

The side panels are pretty much identical thus making it interchangeable. You can swap the one with the front I/O panel on the other side. Fiberflex handle/feet are coated in the SofTouch surface treatment, while the other surfaces are painted in high-standard coating.

OLYMPUS DIGITAL CAMERA

The top portion features the Fiberflex handle coated in SofTouch finish, very useful when carrying your PC to a LAN party or somewhere else.

OLYMPUS DIGITAL CAMERA

Removing the unfiltered mesh cover will show you 2 X 120mm mounts for auxiliary fans or a 240mm radiator.

OLYMPUS DIGITAL CAMERA

On the underside you’ll see the PSU exhaust. The right part is a heat shield that you can easily remove since it’s just held in place by magnets.

OLYMPUS DIGITAL CAMERA

Removing that heat shield you’ll find two hard drive mounts, two 120mm fan mounts and a huge 230mm fan mount.

OLYMPUS DIGITAL CAMERA

The side panel is the location of the front I/O panel. It’s on the side so I guess it should be called the side I/O. Included with it is the the wiring for power, reset, activity LEDs, the audio jack ports and 2x USB 3.0 ports. There is also a plastic bracket where you could mount two 2.5” hard drives.

OLYMPUS DIGITAL CAMERA

BitFenix Prodigy M Interior

Removing the side panel will reveal another mount for hard drives. You might not need this if you don’t have that much hard disks or SSD’s as it only blocks the view of your build.

OLYMPUS DIGITAL CAMERA

Here you can see a huge CPU cut out for easy cooler installation. Four black motherboard stand-offs are pre-installed for mITX installation.

OLYMPUS DIGITAL CAMERA

The front of the case is where you will install your PSU. You can find fan mount holes but unfortunately you can’t install anything on it since it will be entirely covered by your PSU. It has an unfiltered mesh where the PSU get fresh air and exhaust it at the bottom.

OLYMPUS DIGITAL CAMERA

Above the PSU area is a cute 5.25” bay for your ODD or a fan controller. If you find it useless or if it poses a conflict with your graphics card, you could just remove it to have additional space.

OLYMPUS DIGITAL CAMERA

BitFenix is so generous they’ve included two 120mm fans pre-installed at the bottom and the rear part of the case. The base has two 120mm fan mounts, a 230mm fan mount and two 3.25” HDD mount.

OLYMPUS DIGITAL CAMERA

BitFenix Prodigy M Build Guide

  • CPU: Intel Core i5 3550
  • Motherboard: Gigabyte G1.Sniper M3
  • Video Card: HIS HD 7950 IceQ X2 Boost Clock
  • RAM: Avexir Blitz 1.1 16GB 1600Mhz (L337 Edition)
  • HDD: 500GB WDC Blue SATA III
  • Cooler: Antec Kuhler H2O 620
  • Fan: 2 X 120mm and 1 X 140mm Bitfenix Spectre Pro LED

I usually install the CPU, RAM and the cooler bracket to the motherboard before installing it to the case. It is easier for me to install everything with the board outside of its chassis.

OLYMPUS DIGITAL CAMERA

Ample amount of thermal paste is enough for your CPU. Adding more might cause you problems with heat dissipation and leaving your CPU socket messy.

OLYMPUS DIGITAL CAMERA

Now, install the rest of your cooler. You can install it on the top or bottom part of your Prodigy M but the most convenient place I see is at the rear since it is the one nearest to the CPU and for the tube not to mess with other parts. Install the radiator fan aiming towards the radiator to push heat outside of the PC.

OLYMPUS DIGITAL CAMERA

The BitFenix Prodigy comes with a removable PSU bracket for easier PSU installation.

OLYMPUS DIGITAL CAMERA

The Problem

Having a long PSU and a long video card at the same time is a big no for this case. Notice that the video card’s PCB is almost touching the surface of the PSU.

OLYMPUS DIGITAL CAMERA

It also blocks the sockets of the PSU so it is impossible for me to install the video card this way. If you’re going to buy this case, make sure you have a standard-sized PSU or else you’ll going have a limited option for the size of your GPU.

OLYMPUS DIGITAL CAMERA

Since I don’t have an extra standard-sized PSU around, I just resorted to installing the video card on the second PCI-E slot of the motherboard which is not recommended since you will be running your video at a slower PCI-Ex8 lane.

OLYMPUS DIGITAL CAMERA

I always thought that the more the case is compact, the more you’ll get headache managing its cables. Surprisingly, cable management is easy to do with the Prodigy M. With the PSU mounted in this manner, the 24-pin socket of the board and sockets for the video card are just centimeters away.

OLYMPUS DIGITAL CAMERA

Despite the lack of space and cable tie points at the back part of the chassis, there is enough room beside the PSU where you could stuff all those snakes.

OLYMPUS DIGITAL CAMERA

The Twist

Just like me, I guess most people are right handed and we wanted our PC sit on the right of the desk.  The handle and the feet are identical so turning it upside down will show a standard orientation of a motherboard with the PSU mounted in front. I also switched the side panel, the one with the I/O, at the right so I could arrange the front I/O wires at the back of the motherboard.

OLYMPUS DIGITAL CAMERA

Final Thoughts

Just like its little brother Prodigy, The BitFenix Prodigy M is a good looking case. It is an exact replica of the Prodigy exterior wise, but from the inside it is totally different. The PSU mounted at the front is kinda awkward since it is blocking a huge portion of the case which is supposedly the best part where the PC could receive a good ventilation. I’ve had problems installing my HD 7950 since I am using a 180mm CM Silent Pro M2 but having a standard 150mm PSU will free you from those interferences. Using tower coolers wouldn’t be a problem with this case. You can install those mammoth tower coolers like the Noctua NH-D14, CM V8-GTS and even the Phanteks PH-TC14PE. Just like a full-sized PC case, you can install a 240mm radiator on the top, 120mm or even a 140mm radiator on the rear.

Despite of its small issues regarding airflow and clearance between GPU and PSU, the Bitfenix Prodigy M is still a great case. Price wise, at around 4,000 Pesos, you can have a case which is designed for perfection. Modern yet elegant styling, putting one of these in your living room will be an eye-catcher to your visitors.

This review and build guide is an article provided by Carlo “Euro_Bucks” Infante; A Power User, PC enthusiast, and a gamer dad.

BitFenix Prodigy M

8/10

Summary

Just like its little brother Prodigy, The BitFenix Prodigy M is a good looking case. It is an exact replica of the Prodigy exterior wise, but from the inside it is totally different.
